READ & FOLLOW ALL SAFETY GUIDELINES.

SAVE THIS DOCUMENT & DELIVER TO OWNER AFTER INSTALLATION.


IMPORTANT SAFETY CONSIDERATIONS

  1. Properly read through and follow all guidelines, labels, and warnings included with the packaging and luminaire.

  2. Service, maintenance, and installation of all luminaires should be performed by a licensed electrician.

  3. NEVER INSTALL A DAMAGED LUMINAIRE! Contact Wisconsin Lighting Lab, Inc. (WiLL) support immediately if you suspect a product is damaged in any way.

  4. NEVER INSTALL OR SERVICE A LUMINAIRE ON AN ENERGIZED CIRCUIT!! Ensure all power has been fully disconnected.

  5. Follow all NEC (National Electrical Code) and local electrical codes when making electrical and ground connections.

  6. All circumstances cannot be addressed in these guidelines. Practice common sense and use general safety measures when installing or servicing the luminaire.

RISK OF PRODUCT DAMAGE

  1. NEVER EXCEED MAX OPERATING TEMPERATURE! Refer to fixture spec sheet for operating limits

  2. NEVER TOUCH LED COMPONENTS! Contacting the LED components can cause ESD (Electrostatic Discharge) which can reduce the performance and damage the luminaire.

  3. Verify supply voltage is correct, and do not exceed maximum wattage marked on the luminaire label. Never connect components under load.

  4. For safe operation and to prevent malfunction, the luminaire must be properly grounded.

  5. Ensure the luminaire wiring is properly secured to prevent pinching, cutting, cracking, or any other type of damage.

  6. Install luminaires in an area with sufficient ventilation and air flow. All sides of the luminaire must be exposed to airspace unless otherwise noted by WiLL support.

  7. Contact WiLL support if connecting the luminaire to a lighting control device. Lighting control devices include sensors, timers, dimmer packs, etc.

  8. Never use the luminaire for any other purpose than its intended application and environment.

  9. Failure to follow any guidelines listed on this sheet could void product warranties.

Electrical Connections (L-N-G and L-L-G)

Line - Neutral - Ground

  1. Connect supply ground wire to green wire from fixture cord.

  2. Connect the supply line conductor to black wire from the fixture cord.

  3. Connect the supply neutral conductor to white wire from the fixture cord.

Line - Line - Ground

  1. Connect supply ground wire to green wire from fixture cord.

  2. Connect supply line conductor to black wire from fixture cord.

  3. Connect supply line conductor to white wire from fixture cord.

Basic Troubleshooting

Confirm the following:

  • The luminaire is wired properly.
  • The luminaire is grounded properly.
  • The line voltage at the luminaire is correct.

Contact WiLL for additional troubleshooting support.

Louver Install

  1. Remove 4 screws on the base collar of the head.

  2. Lift head off the main body of bollard.

  3. Set the bollard head upside down.

  4. Remove the zip tie holding the connections together.

  5. Disconnect the output wires that go to the LED board.

  6. Remove the 3 nuts holding the head together.

  7. Remove the cone, base collar, and lens.

  8. Remove the two zip ties holding the output wires to the rods.

  9. Install one louver that has a relief cutout for the wires (Align relief with wires).

  10. Install six more louvers making sure that the wires stay on the inside of louvers.

  11. Reverse steps 1-7 to assemble the bollard back together.
